The Challenge | Polar Quest

Design a quest-like game to teach others about polar environments and how they are changing. Use NASA data to help adventurers plan their quest and present them with challenges along the way.

Arctic Trail

Arctic Trail is designed to educate people about climate change. This game will guide you through a journey in the arctic as you attempt to survive and adapt to the changing conditions.

Introduction

One of the main issues luring over the 21st century is the impact of man-made climate change as a consequence of rising carbon dioxide levels in the atmosphere. The impact of these changes has been observed with the higher variability of extreme weather events such as hurricane Irma, the strongest recorded hurricane in the Atlantic Ocean. The abundance of information on climate change paints a decisive picture of where our world is heading towards. Parsing this information to the masses proves to be the main challenge. NASA’s climate change and global warming data visualization system from the MODIS satellite is an essential tool for the accessibility of this information and by using these resources, our role is to create a platform to spark interest and further education in climate change.

Overview

Arctic Trail is the platform that we have designed to educate individuals on the adverse effects of climate change in the arctic region. Our inspiration stems from the classic 1974 computer game - Oregon trail. The original game was designed to teach school children about the realities of 19th century pioneer life on the Oregon Trail. Much like the classic, our game targets a younger demographic to educate them about the potential impact of our actions on the future of this planet. The designed scenario involves an expedition into the arctic circle over the course of 4-9 years, to display the effects of global warming on the biome.

Even though the scenario is fictional, features were integrated to include real events that happen in line with NASA data provided by satellites such as GRACE, ICESat, and MODIS. Key features include:

5 real events with accurate temperature, time, and consequence
Common dangers for the hypothetical traveler traversing the arctic
Information about the flora and fauna and how they are adapting to climate change

The Arctic Trail is created as an education tool template with the ambition of future development. Descriptions of potential considerations are listed in the Future Considerations section below.

Layout

Similar to the original Oregon Trail, the Arctic Trail puts players through a manipulable story line. Starting at Ellesmere Island, between Greenland and Northern Canada, players travel to the Arctic using a sled driven by oxen, while experiencing harsh environments that accompany gradually rising temperatures. The player status updates constantly and a snapshot of the variables are shown in figure 1.

Figure 1: Player Status after 21 months (August 2005)

During the journey, players are prompted with several randomly generated instances. These include:

Shops along the journey to purchase food, hunting equipment, crew and oxen
Attacks from wolves where the player can either fight back or run away. The outcome of the conflict is dependent on the players available resources
Wild arctic berries which provide more food
Frostbite and disease that kill crew members and oxen respectively

We chose a travel path that best exemplified critical events associated with climate change.

The events we chose to include are as follows:

August 2005: You have reached the Ayles Ice Shelf but it has cracked and broken off. This event reduced the arctic sea ice, making it harder for wildlife and you to travel (travel speed reduction). The travel speed decrease can be seen in the video below. Polar bears are starving and their populations are decreasing.
1. Ice shelf area: 66km^2 (15km x 5km x 0.035km)
2. Temperature increasing between 2002-2005
3. Persistent shore winds
4. Survived 45000 years before the break
5. Largest Canadian Arctic ice break in 30 years
December 2005: The population of Musk Ox is rapidly decreasing. With less Ox with you, and your resources low, and you are more likely to freeze without a winter coat. Make sure to grab on at the shop before it’s too late.
1. Temperature: -35.15 Celsius
2. Population of oxen: 150,000 (75% in Canada)
3. Musk Oxen are more vulnerable to disease with climate change
August 2009: Glaciers hold 1% of world’s land ice, but melting it will cause 1/3 of the global sea level rise
1. Temperature: -3.5 Celsius
2. Sea level rise: 3.1mm/year
3. Sea level rise will affect the Americas and Asia first
August 2010: 770,000 square miles less ice than 1981
1. Ward Hunt Ice Shelf breaks off
  1. Surface area: 50km^2
  2. Survived 3000 years
2. Melting ice causes global warming to increase due to a shift from 80:20 reflective capacity to 20:80.
3. Animal habitats will be lost; primarily aquatic plants species
September 2012: Land mass has decreased in area, losing half of the ice cap since 1979.
1. Dec 2003: -11.15 Celsius vs Sep 2012: -7.15 Celsius over same area of land

In addition, the temporal range was also chosen for the game to best represent NASA’s data and include key events. As reflected through NASA cryosphere data, the Arctic ice cap melting hit an all time low during 2012; reaching to only half the size it was in 1979. The comparison of the surface temperature of the same day in 2003 and 2012 are shown in the figure 2 and 3.

Figure 2: Surface temperature on 3rd December 2003 using MODIS satellite imaging

Figure 3: Surface temperature on 3rd December 2012 using MODIS satellite imaging

As time goes on within the game, the average temperature of the region increases at a calculated rate. Over the course of the journey, the melting snow and ice will result in greater resistance and issues during the travel. To simulate this impact, the speed at which the sled moves decreases as the player progresses further within the game.

Background

With NASA data at our disposal, we plan to analyze the data in a easy and comprehensive way so that anybody can learn about the impacts of our carbon footprint. Although climate change has been heavily proven with NASA data and research around the world, the impacts and immediate threats are still reticent and to be effectively communicated. Through the form of interactive game play, Arctic trail offers players a distinctive learning experience. As you journey through the arctic, you will face many obstacles that accurately represent many real time events.

Our designed was based off NASA’s cryosphere earth data. Using the comparison tool while overlaying multiple sensory data in the Arctic, we were able to pinpoint a general path for our game. The data that was used were from the ice surface temperature (aqua and terra) MODIS satellite scans, sea ice and snow cover temporal data sets. The average temperature in the game was calibrated using the cryosphere data, by designing a path along the chosen temperature gradient from our starting point through to the arctic circle.

With the criteria as broad as what the polar quest outlined, the amount of content that we wanted to incorporate was best done through an already established game known as Oregon Trail. As a game that originally taught children about the realities of pioneer life, Oregon Trail was a perfect skeleton to base our Arctic quest. By augmenting the structure, variables, and mechanics, our team repurposed the game to fit our design of an expedition in the Arctic.

Challenge Faced

One of the biggest challenges for us was to integrate our different expertises into a project that could be completed within 48 hours. With one Mechanical Engineer, one Material Engineer, one Mathematician, and one Psychologist/Neuroscientist, we knew that it would be best to expose ourselves to a more creative and novel challenge. With our limited experience in coding, we decided to spend the weekend to learn and develop our game using HTML5, CSS and JavaScript. Greater challenges were faced by our decision to take on 3 new programming languages, and moments of frustration were common amongst our group. The implementation of our ideas and the feasibilities due to the constraints of our skills proved to be difficult. Despite this, we met all the desired design criteria for our game.

Future Considerations

Possible future improvements to the game may include:

At the beginning of the game, have players choose between time eras to play out different timelines/major events. Players could compare eras which would correlate to levels of difficulty during the game.
Incorporating a more robust information text box that could include more descriptive explanations for the events that were happening throughout the game. This would heighten the educational aspect of the game.
More options for transportation that would potentially affect the efficiency of travel

Gameplay
